Jaw movement
Tracking module included
MetiSmile - MR Dental Face 3D scanner
Dhs. 41,083.00
Skip to product information
MetiSmile - MR Dental Face 3D scanner
Dhs. 41,083.00
Available on Click & Collect · Pay by card or cash at pickup, or choose bank transfer at checkout How does it work?
Data integration
DICOM segmentation
Dental workflow
exocad compatibility
Technical specifications
| Model | MetiSmile - MR |
|---|---|
| Resolution | Data Acquisition Camera: 1.3 Mega Pixel HD Texture Camera: 5.0 Mega Pixel |
| Precision | 50μm |
| Field of vision | With a working distance of 500 mm, the FOV is 210*270 mm. |
| Output format | PLY, OBJ, STL |
| White LED colour temperature | 5500K |
| Dimension | 215*50*75mm |
| Weight | 800g |
MetiSmile-MR
Combine 3D facial scanning with mandibular movement capture.
JAW MOVEMENT
Capture mandibular movement
MetiSmile-MR includes the Mandibular Movement Trajectory Tracking module as standard.
MODULE OPTIONS
A clearly defined configuration
Optimal Jaw Relation Determination and Mandibular Movement Trajectory Analysis are separate optional modules. Standard MetiSmile does not include jaw-motion modules. MetiSmile-MR includes mandibular movement trajectory tracking; trajectory analysis and optimal jaw-relation determination are additional optional modules, not automatically included features.
MULTIMODAL ALIGNMENT
Connect facial and dental data
Align multimodal data, work with DICOM segmentation and integrate with compatible exocad workflows. Combine a facial scan with compatible intraoral and CBCT data for a virtual-patient workflow. The combined view helps communicate facial support, smile design and prosthetic planning between the clinician and laboratory.
Export into the design environment
Facial data can be exported as STL, OBJ and PLY for compatible third-party software, including exocad. Jaw-motion data require the appropriate licensed module and compatible downstream workflow.
